Description
| Overview | |
| Presentation | 12 Volt 9Ah Rechargeable Lead Acid battery |
| Lead time | Usually in Stock |
| Nominal Power | |
| 15 mins rate: | 36W/cell to 1.60V/cell |
| Nominal Capacity | |
| 5 hour rate | (1.53A to 10.20V) 7.65Ah |
| 1C | (9A to 9.60V) 5.7Ah |
| 3C | (27A to 9.60V) 3.6Ah |
| Weight | Approx. 2.7kg(5.94Lbs.) |
| Internal Resistance (at 1KHz) | Approx. 14 mΩ |
| Maximum Discharge Current for | |
| 5 seconds: | 135A |
| Charging Methods at 25℃(77℉) | |
| Cycle use: | |
| Charging Voltage Coefficient -5.0mV/℃/cell | 14.4 to 15.0V |
| Maximum Charging Current： | 2.7A |
| Standby use: | |
| Float Charging Voltage Coefficient -3.0mV/℃/cell | 13.5 to 13.8V |
| Operating Temperature Range | |
| Charge | -15℃(5℉) to 40℃(104℉) |
| Discharge | -15℃(5℉) to 50℃(122℉) |
| Storage | -15℃(5℉) to 40℃(104℉) |
| Charge Retention (shelf life) at 20℃(68℉) | |
| 1 month | 97％ |
| 3 month | 92％ |
| 6 month | 85％ |
| Case Material |
| ABS UL94 HB Option: Flammability resistance of (UL94 V-0) |
| Design Life |
| 3-5 Years. |
| Terminal |
| F1 or F2 (Faston Tab 187 or 250) |
